Canon imagePROGRAF TC-20M
Plotter Canon imagePROGRAF TC-20M
Printer 24" and A4 flatbed scanner
Scanner Technology
Scan Technology: Flatbed CIS colour scanner
Maximum Resolution (dpi): Main scan X sub scan: 1,200 x 2,400 dpi*
*Optical resolution is based on the ISO 14473 standard and represents the maximum sampling rate for scanning documents.
Scanning Depth (Input/Output): Colour: RGB each 16bit / each8bit, Greyscale: 16bit / 8bit
Line Scanning Speed: Colour: 3.5 ms/line at 300 dpi, Grayscale / Monochrome: 1.5 ms/line at 300 dpi
Maximum Document Size: A4/LTR(216 x 297mm)
Printer Technology
Printer Type: 4 Colour 24""
Print Technology: Canon Pigment ink 4 colours integrated type (4 chips per print head x 1 print head)
Print Speed:
CAD Drawing: Plain paper (A1, B&W): 0:33 (Standard)
Plain Paper (A1, Colour): 1:03 (Standard)
Poster: Plain Paper (A1): 1:10 (Fast), 2:08 (Standard),
Coated Paper (A1): 3:10 (Fast), 6:05 (Standard)
Print Resolution: 2,400 x 1,200 dpi
Number of Nozzles: Total : 4352 nozzles BK : 1280 nozzles C, M, Y : 1024 nozzles each
Line Accuracy: ±0.1% or less, User adjustments necessary. Printing environment and media must match those used for the adjustments.
Nozzle Pitch: 1,200 dpi x 2 lines
Ink Capacity: Bundled Starter Ink: 280ml (70mlx4 for BK, C, M, Y)
Sales Ink: 70ml (BK, C, M, Y)
Ink Type: Pigment inks : 4 colour BK/C/M/Y
Printer Languages: USB Memory Direct Print1: PDF, JPEG (Exif ver2.2/2.21/2.3)
Standard Memory: 1GB, Expansion slot : No
Hard Drive: No, N/A
Media Feed and Output: Roll Paper : One Roll, Front-loading, Front Output
Cut Sheet : Auto sheet feeder
Media Width: Roll paper : A3, A2, A2+, A1, B2, B3, 18'', 24'', 17'', Cut sheet: 210mm - 297mm
Media Thickness: Roll/Cut : 0.08mm - 0.28mm,
Minimum Printable Length: Roll/Cut : 203.2mm
Maximum Printable Length: Roll paper : 4m, Cut sheet : 432mm
Maximum Media Roll Diameter: 110mm
Media Core Size; Internal diameter of roll core: 2""
Media Feed Capacity: Roll Paper: One roll,
Cut Sheet: 100 sheets(A4), 50 sheets (A3)
Standard Interfaces: USB A Port: USB Memory (Direct Print) - PDF/JPEG (Exif ver2.2/2.21/2.3)
USB B Port: Hi-Speed USB
Ethernet: IEEE802.3u(100BASE-TX) / IEEE802.3(10BASE-T)
Wireless LAN: IEEE802.11n/IEEE802.11g/IEEE802.11b
Consumables:
User Replaceable Items: Ink Tank: PFl-050 (70ml)
Print Head: PF-08
Maintenance Cartridge: MC-32
What's in the Box: Printer, 1 Print head, Power Cable, 1 Set of starter ink tanks, Installation Guide, Safety/Standard Environment leaflet, EU Biocide Sheet, LFP Eur Address Sheet, Flange protective materials sheet
Optional Items: Desktop Basket: BU-06
Printer Stand and Basket: SD-24"
